BAMBOO WINDING COMPOSITE PIPE
Bamboo Winding Composite Pipe
Bio-based composite pipe for municipal water, drainage, and selected industrial pipeline projects
Bamboo winding composite pipe uses bamboo as a reinforcing base with resin-based winding technology to produce large-diameter pipe products. It is suited to selected municipal water supply, drainage, irrigation, and infrastructure projects where medium- and low-pressure pipeline solutions are required.
Replacement Comparison
| Comparison Item | HDPE Pipe | Steel Pipe | Concrete Pipe | Bamboo Composite Pipe |
|---|---|---|---|---|
| Material Structure | Polyethylene | Steel | Concrete | Bamboo fiber plus resin matrix |
| Typical Project Use | Water and drainage | High-pressure transfer | Large-diameter drainage | Municipal water and drainage |
| Diameter Range | DN20-DN1200 | DN15-DN3000+ | DN300-DN4000 | DN300-DN3000 |
| Installation Logic | Heat fusion / electrofusion | Welding / flange | Bell-and-spigot / gasket | Bell-and-spigot / flange with lighter weight |
| Corrosion Resistance | Good | Requires anti-corrosion treatment | General | Good |
Applications
Municipal water supply
Drainage systems
Industrial pipelines
Infrastructure projects
Irrigation and waterworks
Technical Specifications
Nominal DiameterDN300 - DN3000
Pressure Rating0.25MPa - 1.6MPa
Standard Length6m / 12m
Connection MethodBell-and-spigot / Flange
Stiffness ClassSN5000 / SN10000
Reference StandardGB/T 36797-2018
Key Features
Bamboo-fiber reinforced resin winding structure
Large-diameter customization from DN300 to DN3000
Ring stiffness options including SN5000 and SN10000
Suitable for drainage, irrigation, and selected medium/low-pressure transfer scenarios
Bell-and-spigot and flange connection options available
Target Buyers
Municipal contractorsInfrastructure procurement teamsEngineering companiesWater utilitiesBuilding material importers
Not sure which bamboo-based material fits your project? Send your application, target market, and technical requirements.
Submit RequirementsContinue Exploring This Product
Product FAQ
What project scenarios is it suitable for?
It is suitable for selected municipal water supply, drainage, irrigation, and industrial water-transfer scenarios. It is not positioned for high-pressure gas transport or extremely corrosive environments.
Can project technical files be provided?
Yes. Technical data sheets, installation guidance, project references, and test reports can be prepared according to the project scope.
What pressure ratings are available?
Typical pressure levels include 0.25MPa, 0.6MPa, 1.0MPa, and 1.6MPa. Final selection should follow the project design requirement.
What is the largest available diameter?
The current regular range goes up to DN3000. Larger diameters can be reviewed separately.
